Hydraulic Horizontal Sample Extruder

STANDART: TS EN 13286-2, 13286-47, 12697-30; AASHTO T134, T180, T193, T245;
ASTM D698, D1557, D1883, D1559; BS 1377-4, 1924-2, 598-107

LT-S0120 Hydraulic Horizontal Sample Extruder

PRODUCT DETAILS

The Hydraulic Horizontal Sample Extruder is designed for controlled removal of compacted soil and similar specimens from moulds and sample tubes. Its horizontal hydraulic system provides 60 kN maximum extrusion force and a 650 mm maximum stroke, allowing laboratory specimens to be removed safely and efficiently.

Horizontal hydraulic operation: Provides controlled specimen extrusion.
60 kN extrusion force: Supports demanding soil and compacted-material sample preparation.
650 mm maximum stroke: Allows long specimens to be removed from moulds or tubes.
Specimen range: Designed for specimens from Ø35 to Ø101.6 mm.
Standard adaptors: Supplied with ring and tamper adaptors for Ø38 mm and Ø100 mm specimens.
Optional adaptors: Ø50 mm, Ø70 mm and Ø150 mm adaptors are available separately.
Adjustable receiving table: Supports the specimen as it exits the mould.
Lowerable support table: Helps accommodate different specimen and mould arrangements.
External dimensions: 65 × 175 × 75 cm.
Weight: Approximately 150 kg.
Power supply: 220 V, 50–60 Hz.
Product code: LT-S0120.

TECHNICAL SPECIFICATIONS

Product Code	Product Name	Extrusion Force	Specimen Range	Max. Stroke	External Dimensions (cm)	Weight (kg)	Power Supply
LT-S0120	Hydraulic Horizontal Sample Extruder	60 kN	Ø35–101.6 mm	650 mm	65 × 175 × 75	150	220 V, 50–60 Hz

TECHNICAL DOCUMENT

Description

What Is a Hydraulic Horizontal Sample Extruder?

The Hydraulic Horizontal Sample Extruder is designed to remove compacted soil and similar laboratory specimens from moulds or sample tubes in a controlled manner. The hydraulic mechanism applies a steady extrusion force, reducing the need for manual impact or uncontrolled mechanical removal.

Specimen extraction is an important stage in soil-testing workflows. Compacted samples produced during Proctor, CBR and related laboratory procedures may need to be removed from their moulds before further examination or disposal.

The LT-S0120 Hydraulic Horizontal Sample Extruder provides a practical solution for this process.

60 kN Hydraulic Extrusion Force

The LT-S0120 provides a maximum extrusion force of 60 kN.

Its horizontal configuration allows the mould and specimen to be positioned along the extrusion axis. Once the appropriate adaptor is installed, the hydraulic mechanism pushes the specimen through the mould in a controlled direction.

This arrangement helps reduce sudden loads on the sample and makes removal of densely compacted specimens easier.

650 mm Maximum Stroke

The hydraulic system provides a maximum working stroke of 650 mm.

The extended stroke allows the machine to accommodate different mould and sample lengths. Liya Test specifies a nominal working range for specimens between Ø35 and Ø101.6 mm.

An adjustable specimen-receiving table supports the sample as it exits the mould. The table can also be lowered to suit different working arrangements.

Standard Ø38 and Ø100 mm Adaptors

The machine is supplied with the required ring and tamper adaptors for Ø38 mm and Ø100 mm specimens.

These accessories allow the LT-S0120 to support commonly used laboratory specimen dimensions without requiring additional equipment.

Liya Test also lists Ø50 mm, Ø70 mm and Ø150 mm adaptors as separately ordered accessories.

Laboratory Applications

The Hydraulic Horizontal Sample Extruder can support specimen preparation associated with soil compaction, CBR and related laboratory procedures.

The product page references TS EN 13286-2, EN 13286-47, EN 12697-30, AASHTO T134, T180, T193 and T245, together with various ASTM and BS methods. These references represent laboratory procedures in which moulded or compacted specimens may require controlled removal.

LT-S0120 Technical Construction

The machine has external dimensions of approximately 65 × 175 × 75 cm and weighs approximately 150 kg.

Its electrical requirement is listed as 220 V, 50–60 Hz.

Overall, the LT-S0120 Hydraulic Horizontal Sample Extruder combines 60 kN hydraulic force, a 650 mm stroke and interchangeable adaptors to provide controlled specimen removal for soil-mechanics and quality-control laboratories.
