STANDARDS: EN 1097-6, 12390-7
LT-G0290 Thermometer, 1 Channel Measuring Range: -50 + 1300 C
LT-G0291 Thermometer, 1 Channel. Measuring Range: -200 + 1300 C
LT-G0292 Thermometer, 2 Channels. Measuring Range: -200 + 1300 C
LT-G0293 Thermometer, 4 Channels. Measuring Range: -200 + 1300 C
LT-G0220/1 K-Type Thermocouple Cable, Type: KTTE2X0,5T
LT-G0220/2 Connector, Type: OMTS-K-E
Thermometers are used for monitoring of temperature development of mass concrete. The number of measurement points for connectors and the cable length needed for each measurement point should be indicated.
K-Type Thermocouple Cable and Connector should be ordered separately.
LT-G0290, LT-G0291, LT-G0292 Models are supplied with 9V battery and User Manual and LT-G0293 Model is supplied with Lithium-Ion battery, Transport case and User Manual.
| Product Code | Product Name | Measuring Range (°C) | Accuracy (°C) | Resolution (°C) | Dimensions (cm) | Weight (kg) |
| LT-G0290 | Thermometer, 1 Channel | -50 + 1300 | ±1 | 1 | 15x7x3,5 | 0,400 |
| LT-G0291 | Thermometer, 1 Channel | -200 + 1300 | ±1.1 or ±0.4 % of reading value | 0.1 < 999 1 > 1000 | 15x7x3,5 | 0,190 |
| LT-G0292 | Thermometer, 2 Channel | -200 + 1300 | ±1.1 or ±0.4% of reading value | 0.1 < 999 1 > 1000 | 15x7x3,5 | 0,190 |
| LT-G0293 | Thermometer, 4 Channel | -200 + 1300 | From -200 to 0; ±0.4 ±0.3 % of reading From 0 to 1300; ±0.4 | 0.1 | 21x11x6 | 0,485 |
| LT-G0295/1 | K-Type Thermocouple Cable, Type: KTTE2X0,5T | — | — | — | 10x10x0,5 | 0,01 |
| LT-G0295/2 | Connector, Type: OMTS-K-E | — | — | — | 2x1x0,5 | 0,01 |
